COLD AND HOT TEMPERATURE CONTROLLER
1.WINWAY COLD AND HOT TEMPERATURE CONTROLLER can cool and heat the equipment according to the production demand; The product is easy to operate, stable performance, energy saving and high efficiency, high degree of automatio Nominal cooling capacity calculated according to:Inlet/outlet chilled fluid temperature 12℃/7℃,inlet/oultlet cooling air temperature 30℃/40℃.
2.Working condition:The temperature range circulating water is from 5℃-50℃,temperature difference between inlet and outlet chilled fluid is from 2℃-8℃.
3.Circulated water is clean water,according to standard GB/T 18430.1-2007,D
4.It is better to run the chiller while the ambient temperature at or below 35℃
5.We reserve the right to modify the above information without prior notice
1.Including both heating and cooling temperature control system,easily to shift quickly from cooling and heating with one-press operation based on production needs,temperature control maintains within ±2℃.
2.Installed with brand new famous compressor from USA and Japan with safety protection inside,which makes low noise and provides long stable durability.
3.High efficient evaporator and condenser could increase heat exchange efficiency 25% and save energy consumption more than 30%.
4.With sufficient protections,intelligent fault indication and buzzer alarm,which is high-automatized and requires no dedicated operations.
